Case IH Magnum 220

Specifications

  • Manufacturer: Case IH
  • Model: Magnum 220
  • Type: 4WD, Rowtrac, & Track Tractors
  • Classification Horsepower: 220
  • Drive Type: Wheeled Tractor
  • Drive Configuration: 4wd
  • Engine Power Hp [ Kw ]: 220 [162]
  • Maximum Power Hp [ Kw ]: 260 [191]
  • Pto Power Hp [ Kw ]: 185 [138]
  • 540 Available?: Yes
  • Engine Make: Case Ih Fpt
  • Engine Model: 6.7 L
  • Transmission Type: Full Powershift
  • Number Of Forward Speeds: 19
  • Number Of Reverse Speeds: 4
  • Number Of Remote Valves: 3 Std; 4 Or 5 Opt
  • 3-point Hitch Category: Category 3/3n
  • Standard Lift Capacity 24 Inches Behind Pin Lbs [ Kg ]: 13600 [6170]
  • Wheelbase/trackbase Inches [ Mm ]: 118 [3000]
  • Overall Width Inches [ Mm ]: 119 [3020]
